Detailed Product Description
|
Cable Description
|
17VATC
|
19VATC
|
21VATC
|
|
|
Inches
|
mm
|
Inches
|
mm
|
Inches
|
mm
|
|
Inner Conductor Diameter
|
0.044
|
1.13
|
0.039
|
1.00
|
0.039
|
1.00
|
|
Diameter Over Dielectric
|
0.189
|
4.80
|
0.189
|
4.80
|
0.189
|
4.80
|
|
Pet Foil
|
|
|
|
|
|
|
|
Diameter Over Conductor
|
0.216
|
5.50
|
0.216
|
5.50
|
0.216
|
5.50
|
|
Diameter Over Jacket
|
0.267
|
6.80
|
0.267
|
6.80
|
0.267
|
6.80
|
|
Impedance
|
75 Ohms
|
75 Ohms
|
75 Ohms
|
|
Capacitance
|
53(pF/m)
|
52(pF/m)
|
52(pF/m)
|
|
Return Loss
|
VHF30-310MHz﹥﹦
|
22dB
|
|
UHF30-460MHz﹥﹦
|
22dB
|
|
Screening Attenuation
|
VHF5-50MHz﹥﹦
|
68dB
|
|
UHF200-upward MHz﹥﹦
|
70dB
|
|
17VATC
|
19VATC
|
21VATC
|
|
Frequency
(mm)
|
Maximum
(dB/100FT)
|
Maximum
(dB/100m)
|
Frequency
(mm)
|
Maximum
(dB/100FT)
|
Maximum
(dB/100m)
|
Frequency
(mm)
|
Maximum
(dB/100FT)
|
Maximum
(dB/100m)
|
|
47
|
1.31
|
4.30
|
47
|
1.46
|
4.80
|
47
|
1.48
|
4.85
|
|
100
|
1.68
|
5.50
|
100
|
1.98
|
6.5
|
100
|
2.00
|
6.55
|
|
300
|
2.96
|
9.70
|
300
|
3.26
|
10.70
|
300
|
3.28
|
10.75
|
|
800
|
5.03
|
16.5
|
800
|
5.49
|
18.00
|
800
|
5.64
|
18.50
|
|
1000
|
5.80
|
19.00
|
1000
|
6.10
|
20.00
|
1000
|
6.25
|
20.50
|
|
1350
|
6.86
|
22.50
|
1350
|
7.17
|
23.50
|
1350
|
7.32
|
2400
|
|
1750
|
7.87
|
25.80
|
1750
|
8.17
|
26.80
|
1750
|
8.33
|
27.30
|
|
2150
|
8.85
|
29.00
|
2150
|
9.15
|
30.00
|
2150
|
9.30
|
30.50
|
|
2400
|
9.39
|
30.80
|
2400
|
9.70
|
31.80
|
2400
|
9.85
|
32.30
|
|
3000
|
10.80
|
31.60
|
3000
|
11.10
|
32.30
|
3000
|
10.60
|
34.00
|
